Bed Dimensions –

Front double m (Imperial) – 2.08×1. 69 (6`8” x 5`6”)



BODY STYLES

  • Lo-Line with over cab storage area and Skyline panoramic opening window

ENGINE & CHASSIS

  • Fiat Ducato chassis type – Light
  • Wheel base (mm) – 3450
  • Drive – Front
  • Number of cylinders – 4
  • Number of gears (forward) – 6
  • 140 Mulitjet II Euro 6D Max. torque 320Nm@1400rpm
  • Intercooler



WEIGHT & DIMENSIONS

  • 03 (9’11”)
  • Overall length m (Imperial) – 6.44 (21’1″)
  • Overall width mirrors folded m (Imperial) – 2.35 (7’9″)
  • Overall width mirrors unfolded m (Imperial) – 2.77 (9’1″)
  • Fresh water capacity (ltr) – 135
  • Waste water capacity (ltr) – 85
  • Gas bottle storage (Calor propane) (kg) – 1×7, 1×13
  • Fuel tank capacity (ltr) – 75
  • front axle loading (kg) 1850
  • rear axle loading (kg) 2000
  • gross weight (all 3500kg models can be upgraded to 3650kg) (kg)
  • gross train weight (with 3650kg upgrade MGTW increases to 4900kg) 4750
  • Mass in running order (kg) 3200
  • towing weight (kg) 1250
  • Tyres – 225/75 R16CP
  • Awning size (m) 3.5



MAX. BED MEASUREMENTS

  • Front double m (Imperial) – 2.08×1. 69 (6`8” x 5`6”)



FLOOR COVERINGS & UPHOLSTERY

  • Scatter cushions (qty)
  • 2
  • Tilly luxury upholstery with full curtains
  • Side wall ventilation boards
  • Cushioned vinyl floor with removable bound-edged carpets
  • Fire retardant upholstery

KITCHEN FEATURES



  • Illuminated splash back
  • Flush fitting 4 ring hob (3 x gas, 1 x 800W electric), full oven/grill and pan store
  • 96 ltr fridge with removable freezer compartment
  • Fully fitted 800W microwave
  • Cutlery storage
  • Domestic style single lever mixer taps
  • Domestic style worktops
  • Inset sink with flush-fitting cover and dedicated sink cover storage
  • Domestic drawer system with soft close

WASHROOM FEATURES

  • Domestic style bathroom taps and shower head/controls
  • Domestic style washroom doors
  • Fully enclosed seamless shower cubicle
  • High level foldaway drying rail in shower
  • Variable shower control and riser tower
  • Storage cabinet
  • Blown air heating outlets to washroom area
  • Large mirror
  • 12V electric flush toilet with removable cassette on wheels

LIVING ROOM FEATURES

  • Easy access to bed boxes
  • Moyet Oak solid plywood interior furniture
  • Two tone upper locker doors
  • Textured ‘cool grey’ upper locker doors
  • Pleated flyscreens/blinds to all opening windows
  • Cocktail cabinet
  • Free standing table
  • Metal rollerball drawer runners
  • On the move heating

CAB AREA INTERIOR FEATURES

  • Fully upholstered height adjustable driver and passenger Captain’s seats with twin armrests and swivel seat base
  • Techno dash – brushed alloy effect
  • Bottle/cup holder and USB charging point
  • Air-con cooled water bottle storage
  • High level instrument cluster with chrome bezels
  • Steering wheel controls for radio and telephone
  • Cab air conditioning
  • Multi-function trip computer
  • Digital clock
  • Storage pockets in both cab doors
  • Pleated blinds to cab windows
  • Folding tablet/smartphone holder to dashboard
  • Motorhome specific’ Western European satellite navigation system (Media Pack)
  • Colour reversing camera integrated into touchscreen head unit (Media Pack)
  • 5″ Avtex widescreen TV/DVD player (Media Pack)

VENTILATION

  • Side wall ventilation boards
  • Included
  • Double glazed windows with pleated flyscreens and blinds
  • Wind up panoramic roof light
  • 12V 3 speed roof fan/ventilator
  • Side wall ventilation

WATER & GAS

  • Fresh/waste water tank gauge
  • Pressurised water system
  • Waste water tank pipe extension

ELECTRICAL & GAS FEATURES

  • Touchscreen control panel with digital display – ability to monitor vehicle remotely
  • Ambient concealed LED over locker lighting
  • 12V under locker LED dimmable lighting
  • 12V under locker LED reading lights
  • 12V courtesy wardrobe light
  • 230V socket(s)
  • Coaxial TV aerial, 12V and 230V socket
  • Battery charge/discharge digital readout (amps)
  • Digital clock with alarm facilities
  • Digital inside and outside temperature guide
  • Engine battery condition indicator
  • Variable rate transformer/charger
  • Illuminated entrance door area
  • Leisure battery condition indicator (volts)
  • RCD unit
  • Rear speakers
  • Combi 4kW gas 230V heater/hot water 12V blown air incl. digital control panel
  • Auto-Trail ‘Connect’ – Thatcham CAT 7 approved tracking subscription (To be purchased through myautotrail.co.uk website)

INSULATION & STRENGTH

  • 5 year warranty for conversion (T&C’s apply)
  • 5 year body construction integrity warranty (T&C’s apply)
  • 2 year Fiat warranty for chassis (T&C’s apply)
  • Grade 3 insulation
  • Full vinyl underfloor protection
  • Laminated wall construction (full thickness = 40mm)
  • Laminated floor construction (full thickness = 45mm)
  • Laminated roof construction (full thickness = 40mm)

EXTERIOR STYLE & FEATURES

  • Brushed aluminium front grille and lower skid plate
  • Chrome headlamp surrounds
  • GRP high gloss aerodynamic overcab roof moulding
  • GRP high gloss rear panel with LED light clusters
  • Integral spare wheel (steel on rear panel) and moulded cover
  • GRP high gloss scratch/damage resistant side walls
  • Distinctive Auto-Trail exterior graphics
  • Acrylic capped ABS side skirts
  • Colour coded front bumper
  • Front mud flaps
  • Rear mud flaps
  • Integral moulded entrance step with removable mat
  • High security entrance door with central locking with blind, waste bin, flyscreen and Auto-Trail umbrella with storage
  • Electrically operated step
  • Adjustable, electrically operated heated exterior mirrors with blind spot mirror
  • Electrically operated cab windows
  • Exterior cold shower unit
  • External gas BBQ point
  • 16″ Fiat alloy wheels (including steel type spare wheel)

STORAGE & ACCESS

  • Exterior storage/access locker
  • Cantilever side underfloor storage locker

EXTERNAL LIGHTING

  • Daytime Running Lights (DRLs) to headlamps
  • LED exterior awning light
  • LED front marker lights
  • LED rear marker lights
  • Side running lights
  • LED rear lights
  • 3rd high level brake light

POWER

  • Leisure battery (92AH AGM) (qty) x 1
  • 100W solar panel
  • Exterior 230V socket (situated under rear bed/storage areas)

VISIBILITY & VENTILATION

  • Double glazed windows with pleated flyscreens and blinds
  • Wind up panoramic roof light
  • 12V 3 speed roof fan/ventilator

SAFETY

  • Cruise control with speed limiter
  • ABS braking
  • Disc brakes front and rear
  • Central locking (to cab and habitation door)
  • Fitted engine immobiliser
  • Spare wheel (steel type)
  • ECWVTA compliance to all relevant EU standards
  • National Caravan Council approved
  • Entrance door grab handle
  • Flame failure shut-off valves to all gas appliances
  • Isolation taps to all gas appliances
  • Smoke alarm/CO2 alarm
  • Fire extinguisher
